Fabtech K1157M Ball Joint Control Arm Lift System

Fabtech
FABK1157M
This is a SPECIAL ORDER part. This item can be brought in either with a stock order or on its own. Contact us today to discuss available options BEFORE ordering.
$1,656.30
$1,656.30
$1,656.30

Verify fitment with your vehicle
 More payment options
Fabtech K1157M Ball Joint Control Arm Lift System

Vendor: Fabtech

Fabtech K1157M Ball Joint Control Arm Lift System

$1,656.30

Vendor: Fabtech

Fabtech K1157M Ball Joint Control Arm Lift System

$1,656.30
Ball Joint Control Arm Lift System; 3.5 in. Lift; Stealth; For PN[FTS21276/FTS6341/FTS6019];
This new 4 System capitalizes on Toyota Tundras large wheelwell opening to allow use of 35 tall tires with minimum lift height. The design of this 4 System is a new style of suspension that delivers improved performance with fewer parts, and comes with an affordable price. The system includes replacement upper control with a .120 wall DOM arm with heavy duty extended range ball joints that provide additional strength to the front suspension. Heavy duty extended length steering knuckles are included to provide proper functionality of the factory ESC (Electronic Stability Control) with 35 tall tires. The knuckles retain the stock track width keeping the tires under the front fenders. The front differential is relocated to keep CV angles proper during the full range of travel. Front bump stop extensions and brake hose relocation brackets complete the front suspension. Rear lift comes from a 1 lift block and u-bolt system to level the stance of the vehicle. The 4 System is available with a spacer system to retain the factory Coilover shocks and rear Performance shocks.
  • Simplified Design With Fast Install
  • Steering Knuckles Retain Proper ESC
  • No Loss Of Ground Clearance
  • 2 to 3 Hours Installation
  • No Drilling Required
  • No Welding Required
  • No Cutting Required
  • No Driveshaft Modification

Application Summary:

Year Make/Model
2020-2021 GMC Sierra 2500 HD
2020-2021 GMC Sierra 3500 HD

This Product Page / Kit Number is only for Reference

To Purchase This Kit, Please place your order using the following list of parts that make up the kit;

FTS21276 Qty. Reqd.= 1, FTS6019 Qty. Reqd.= 2, FTS6341 Qty. Reqd.= 2

Year
Make
Model
Submodel
Engine
Notes
2022
Chevrolet
Silverado 2500 HD
6.6L
3.5 in. Lift; Stealth; For PN[FTS21276/FTS6341/FTS6019]
2023
Chevrolet
Silverado 2500 HD
Custom
6.6L
3.5 in. Lift; Stealth; For PN[FTS21276/FTS6341/FTS6019]
2020 - 2021
Chevrolet
Silverado 2500 HD
High Country
2023
Chevrolet
Silverado 2500 HD
High Country
6.6L
3.5 in. Lift; Stealth; For PN[FTS21276/FTS6341/FTS6019]
2020 - 2021
Chevrolet
Silverado 2500 HD
LT
2023
Chevrolet
Silverado 2500 HD
LT
6.6L
3.5 in. Lift; Stealth; For PN[FTS21276/FTS6341/FTS6019]
2020 - 2021
Chevrolet
Silverado 2500 HD
LTZ
2023
Chevrolet
Silverado 2500 HD
LTZ
6.6L
3.5 in. Lift; Stealth; For PN[FTS21276/FTS6341/FTS6019]
2023
Chevrolet
Silverado 2500 HD
WT
6.6L
3.5 in. Lift; Stealth; For PN[FTS21276/FTS6341/FTS6019]
2022
GMC
Sierra 2500 HD
6.6L
3.5 in. Lift; Stealth; For PN[FTS21276/FTS6341/FTS6019]
2020 - 2021
GMC
Sierra 2500 HD
AT4
2020 - 2021, 2023
GMC
Sierra 2500 HD
AT4
6.6L
3.5 in. Lift; Stealth; For PN[FTS21276/FTS6341/FTS6019]
2020 - 2021
GMC
Sierra 2500 HD
Base
2020 - 2021
GMC
Sierra 2500 HD
Base
6.6L
3.5 in. Lift; Stealth; For PN[FTS21276/FTS6341/FTS6019]
2020 - 2021
GMC
Sierra 2500 HD
Denali
2020 - 2021, 2023
GMC
Sierra 2500 HD
Denali
6.6L
3.5 in. Lift; Stealth; For PN[FTS21276/FTS6341/FTS6019]
2023
GMC
Sierra 2500 HD
Pro
6.6L
3.5 in. Lift; Stealth; For PN[FTS21276/FTS6341/FTS6019]
2020 - 2021
GMC
Sierra 2500 HD
SLE
2020 - 2021, 2023
GMC
Sierra 2500 HD
SLE
6.6L
3.5 in. Lift; Stealth; For PN[FTS21276/FTS6341/FTS6019]
2020 - 2021
GMC
Sierra 2500 HD
SLT
