Size | 8 -inch | |
Impedance | 4 ohms | |
Cone Material | Carbon-glass fiber | |
Surround Material | Butyl rubber | |
Ideal Sealed Box Volume (cubic feet) | 0.5 | |
Ideal Ported Box Volume (cubic feet) | 0.5 | |
Port diameter (inches) | N/A | |
Port length (inches) | N/A | |
Free-Air | No | |
Dual Voice Coil | No | |
Sensitivity | 78 dB at 1 watt | |
Frequency Response | 40 - 500 Hz | |
Max RMS Power Handling | 150 | |
Peak Power Handling (Watts) | 600 | |
Top Mount Depth (inches) | 2 3/4 | |
Bottom Mount Depth (inches) | 3 5/16 | |
Cutout Diameter or Length (inches) | 7 3/16 | |
Vas (liters) | 10.7 | |
Fs (Hz) | 43 | |
Qts | 0.812 | |
Xmax (millimeters) | 6.5 | |
Parts Warranty | 2 Years | |
Labor Warranty | 2 Years |
