Kenwood Excelon Class D Mono Power Amplifier
X502-1
Product highlights:
- mono subwoofer amplifier
- 300 watts RMS x 1 at 4 ohms (500 watts RMS x 1 at 2 ohms)
- CTA-2006 compliant
- Class-D amplifier design
- variable low-pass filter (50-200 Hz at 24 dB/octave)
- bass boost (0-18 dB at 40 Hz)
- subsonic filter (25 Hz at 24 dB per octave)
More Info:
- optional KCA-RC01A wired remote level control available
- preamp and speaker-level inputs
- wiring and hardware not included with amplifier
- 8-gauge power and ground leads recommended
- fuse rating: 30A x 2
- 8-7/16"W x 2-1/8"H x 5-15/16"D
- warranty: 2 years
- MFR # X502-1
What's in the box:
- Mono subwoofer amplifier
- Two 30-amp ATC fuses (installed)
- Terminal cover (installed)
- 8" Speaker level input harness
- Four 5/8" Screws
- Instruction manual (English/ French/ Spanish)
Features and amp; specs
| Performance | ||
|---|---|---|
| RMS Power Output (Watts x Channels) | 300 x 1 | |
| Peak Power Output (Watts x Channels) | 1000 x 1 | |
| Power at 2 Ohms (Watts x Channels) | 500 x 1 | |
| Bridged Power (Watts x Channels) | N/A | |
| Minimum Impedance Bridged | N/A | |
| Minimum Impedance Unbridged | 2 | |
| Minimum Impedance | 2 | |
| Best Frequency Response | 20-200 Hz | |
| THD at Rated RMS Power | 1% | |
| Signal to Noise Ratio | 85 dB | |
| Input Voltage | 14.4v | |
| Features | ||
| Amplifier Class | D | |
| Low-Pass Crossover Frequency | 50-200 Hz | |
| Low-Pass Slope (dB/octave) | 24 dB/octave | |
| High-Pass Crossover Frequency | N/A | |
| High-Pass Slope (dB/octave) | N/A | |
| Bass Boost | 0-18 dB | |
| Bass Boost Frequency | 40 Hz | |
| Fan Cooled | No | |
| Fuse Rating | 60 | |
| Speaker Level Inputs | Harness | |
| Preamp Outputs | No | |
| Width (inches) | 8-7/16 | |
| Height (inches) | 2-1/8 | |
| Depth (inches) | 5-15/16 | |
| Parts Warranty | 2 Years | |
| Labor Warranty | 2 Years | |
