Kenwood Excelonand Reference Series mono subwoofer amplifier and mdash; 1,000 watts RMS x 1 at 2 ohms

XR1001-1


Product highlights:

  • mono subwoofer amplifier
  • 500 watts RMS x 1 at 4 ohms (1,000 watts RMS x 1 at 2 ohms)
  • CTA-2006 compliant
  • Class-D amp design and mdash; frequency response: 20-200 Hz
  • variable low-pass filter (50-200 Hz, 12 or 24 dB/octave)
  • variable subsonic (infrasonic) filter (15-40 Hz, 24 dB/octave)
  • adjustable bass boost (0-18 dB at 40 Hz)
  • wired remote volume control included
More Features:
  • cooling fan
  • preamp inputs and outputs
  • speaker-level inputs (require speaker wire to RCA adapters) feature signal-sensing turn-on
  • fuse rating: 40A x 3
  • wiring and hardware not included with amplifier
    • 4-gauge power and ground leads recommended
  • 12-9/16"W x 2-1/8"H x 7-1/4"D
  • warranty: 2 years
  • MFR # XR1001-1

What's in the box:

  • Mono subwoofer amplifier
  • Three 40-amp mini blade fuses (installed)
  • Remote Commander
  • Flat washer
  • Hex nut
  • 20' Remote cable (RJ-14 modular plugs on each end)
  • 4mm Allen wrench
  • 2.5mm Allen wrench
  • Four 5/8" Self-tapping screws
  • Instruction manual (Eng/ Fren/ Span)
  • Warranty card

Features and amp; specs

Performance
RMS Power Output (Watts x Channels) 500 x 1
Peak Power Output (Watts x Channels) 2000 x 1
Power at 2 Ohms (Watts x Channels) 1000 x 1
Bridged Power (Watts x Channels) N/A
Minimum Impedance Bridged N/A
Minimum Impedance Unbridged 2
Minimum Impedance 2
Best Frequency Response 20-200 Hz
THD at Rated RMS Power 1%
Signal to Noise Ratio 85 dB
Input Voltage 14.4v
Features
Amplifier Class D
Low-Pass Crossover Frequency 50-200 Hz
Low-Pass Slope (dB/octave) 12 or 24 dB/oct
High-Pass Crossover Frequency N/A
High-Pass Slope (dB/octave) N/A
Bass Boost 0-18 dB
Bass Boost Frequency 40 Hz
Fan Cooled Yes
Fuse Rating 120
Speaker Level Inputs RCA
Preamp Outputs 1 pair
Width (inches) 12-9/16
Height (inches) 2-1/8
Depth (inches) 7-1/4
Parts Warranty 2 Years
Labor Warranty 2 Years
