Kenwood Excelon Reference XR401-4 4-channel car amplifier 75 watts RMS x 4

Kenwood Excelon Reference XR401-4 4-channel car amplifier 75 watts RMS x 4

KENWOOD
KENXR401-4
1 In Stock
$498.00
$549.99
$498.00

Universal Fit
This product may require modification.
 More payment options
Kenwood Excelon Reference XR401-4 4-channel car amplifier 75 watts RMS x 4

KENWOOD

Kenwood Excelon Reference XR401-4 4-channel car amplifier 75 watts RMS x 4

$549.99 $498.00
Kenwood Excelon Reference XR401-4 4-channel car amplifier 75 watts RMS x 4

KENWOOD

Kenwood Excelon Reference XR401-4 4-channel car amplifier 75 watts RMS x 4

$549.99 $498.00
Description

Kenwood Excelon Reference Series 4-channel car amplifier and mdash; 75 watts RMS x 4

XR401-4

Product highlights:

  • 4-channel amplifier
  • 75 watts RMS x 4 at 4 ohms (100 watts RMS x 4 at 2 ohms)
  • 200 watts RMS x 2 bridged output at 4 ohms (4-ohm stable in bridged mode)
  • CTA-2006 compliant
  • Class-D amp design and mdash; frequency response: 20-40,000 Hz
  • variable low- and high-pass filters (50-200 Hz or 2.5k-10k Hz, 12 dB/octave)
  • preamp inputs only
  • fuse rating: 30A x 2
  • wiring and hardware not included with amplifier
    • 4-gauge power and ground leads recommended
  • 8-11/16"W x 1-7/16"H x 7"D
  • warranty: 2 years
  • MFR # XR401-4

What's in the box:

  • 4-Channel amplifier
  • Two 30-amp ATM mini blade fuses (installed)
  • Wired Remote Commander
  • Flat washer
  • Hex nut
  • 20' Remote cable (RJ-14 modular plugs on each end)
  • 4mm Allen wrench
  • 2.5mm Allen wrench
  • Four 5/8" Self-tapping screws
  • Instruction manual (English/ French/ Spanish)
  • Warranty card

Features and amp; specs

Performance
RMS Power Output (Watts x Channels) 75 x 4
Peak Power Output (Watts x Channels) N/A
Power at 2 Ohms (Watts x Channels) 100 x 4
Bridged Power (Watts x Channels) 200 x 2
Minimum Impedance Bridged 4
Minimum Impedance Unbridged 2
Minimum Impedance 2
Best Frequency Response 20-40k Hz
THD at Rated RMS Power 1%
Signal to Noise Ratio 76 dB
Input Voltage 14.4v
Features
Amplifier Class D
Low-Pass Crossover Frequency 50-200 or 2.5k-10k
Low-Pass Slope (dB/octave) 12 dB/octave
High-Pass Crossover Frequency 50-200 or 2.5k-10k
High-Pass Slope (dB/octave) 12 dB/octave
Bass Boost No
Bass Boost Frequency N/A
Fan Cooled No
Fuse Rating 60
Speaker Level Inputs No
Preamp Outputs No
Width (inches) 8-11/16
Height (inches) 1-7/16
Depth (inches) 7
Parts Warranty 2 Years
Labor Warranty 2 Years

Fitment
Universal Fit
