Kenwood Excelon Reference Series mono subwoofer amplifier and mdash; 600 watts RMS at 2 ohms
XR601-1
Product highlights:
- mono subwoofer amplifier
- 400 watts RMS x 1 at 4 ohms (600 watts RMS x 1 at 2 ohms)
- CTA-2006 compliant
- Class-D amp design and mdash; frequency response: 20-200 Hz
- variable low-pass filter (50-200 Hz at 24 dB/octave)
- adjustable bass boost (0-18 dB at 40 Hz)
- wired remote volume control included
- preamp inputs only
- fuse rating: 30A x 3
- wiring and hardware not included with amplifier
- 4-gauge power and ground leads recommended
- 8-11/16"W x 1-3/8"H x 7"D
- warranty: 2 years
- MFR # XR601-1
What's in the box:
- Mono subwoofer amplifier
- Three 30A ATM mini-blade fuses (installed)
- Remote Commander
- Flat washer
- Hex nut
- 20' Remote cable (RJ-14 modular plugs on each end)
- 4mm Allen wrench
- 2.5mm Allen wrench
- Four 5/8" self-tapping screws
- Instruction Manual (Eng / Fren / Span)
- Warranty card
Features and amp; specs
| Performance | ||
|---|---|---|
| RMS Power Output (Watts x Channels) | 400 x 1 | |
| Peak Power Output (Watts x Channels) | --- | |
| Power at 2 Ohms (Watts x Channels) | 600 x 1 | |
| Bridged Power (Watts x Channels) | N/A | |
| Minimum Impedance Bridged | N/A | |
| Minimum Impedance Unbridged | 2 | |
| Minimum Impedance | 2 | |
| Best Frequency Response | 20-200 Hz | |
| THD at Rated RMS Power | 1% | |
| Signal to Noise Ratio | 78 dB | |
| Input Voltage | 14.4v | |
| Features | ||
| Amplifier Class | D | |
| Low-Pass Crossover Frequency | 50-200 Hz | |
| Low-Pass Slope (dB/octave) | 24 dB/octave | |
| High-Pass Crossover Frequency | N/A | |
| High-Pass Slope (dB/octave) | N/A | |
| Bass Boost | 0-18 dB | |
| Bass Boost Frequency | 40 Hz | |
| Fan Cooled | No | |
| Fuse Rating | 90 | |
| Speaker Level Inputs | No | |
| Preamp Outputs | No | |
| Width (inches) | 8-11/16 | |
| Height (inches) | 1-3/8 | |
| Depth (inches) | 7 | |
| Parts Warranty | 2 Years | |
| Labor Warranty | 2 Years | |
