Description

6" X 9" PRO Full-Range Co-Ax Horn Speaker

MP694

  • 150W RMS/300W MAX Power Handling
  • Ferrite Strontium High Temp Magnet structure
  • Heavy Duty Die-cast Aluminum Basket
  • 1.5" 4 Ohm - Single Layer High Temp Voice Coil with Black Coated Voice Coil former for Woofer
  • 1.0" 8 Ohm - Single Layer High Temp Voice Coil for Tweeter
  • Advanced Voice Coil Heat Sink Design for Better Heat Dissipation
  • Frequency Response: 80Hz -18Khz
  • High Sensitivity 101dB 1W/1M
  • 12dB Crossover
  • Mounting Depth: 3.99" / 101.3mm
  • Mounting Diameter: 8.86" x 5.98" / 225 x 152mm

Specifications

SPL (dB-MidBass) 95.6
SPL (dB-Tweeter) 107
Re(ohm)[series] 3.2
Qms 9.42
Qes 0.43
Qts 0.42
Fs(Hz) 82.6
Vas(L) 18.2
Cms(mm/N) 0.25
Mms(g) 15.1
Sd(m2) 229.7
BL(T*M) 7.6
Xmax(mm) 1.0
Pwr(W) NOM/MAX 150/**300
Total Diameter 9.33X6.57 (237X167) in. (mm)
Mounting Diameter 8.86X5.98 (225X152) in. (mm)
Mounting Depth 3.99 (101.3) in. (mm)
Total Depth 4.26 (108.3) in. (mm)
Magnet Diameter 3.94 (100) in. (mm)
