Description

8" PRO Full-Range Co-Ax Horn Speaker

MP84

  • 200W RMS/400W MAX Power Handling
  • Ferrite Strontium High Temp Magnet Structure
  • 1.5" 4 Ohm - Single Layer High Temp Voice Coil with Black Coated Voice Coil former for Woofer
  • 1.0" 8 Ohm - Single Layer High Temp Voice Coil for Tweeter
  • Heavy Duty Die-cast Aluminum Basket
  • Advanced Voice Coil Heat Sink Design for Better Heat Dissipation
  • Frequency Response: 80Hz -18Khz
  • High Sensitivity 103dB 1W/1M
  • 12dB Crossover
  • Mounting Depth: 3.98" / 101mm
  • Mounting Diameter: 7.09" / 180mm

Specifications

SPL (dB-MidBass) 95.2
SPL (dB-Tweeter) 107
Re(ohm)[series] 3.2
Qms 12.46
Qes 0.42
Qts 0.41
Fs(Hz) 69.43
Vas(L) 27.5
Cms(mm/N) 0.43
Mms(g) 12.3
Sd(m2) 213.8
BL(T*M) 6.4
Xmax(mm) 1.0
Pwr(W) NOM/MAX 200/**400
Total Diameter 8.31 (211) in. (mm)
Mounting Diameter 7.09 (180) in. (mm)
Mounting Depth 3.98 (101) in. (mm)
Total Depth 4.25 (108) in. (mm)
Magnet Diameter 4.06 (103) in. (mm)
