The Edelbrock Pro-Flo 4 EFI Kit #36170 for Chevy Gen IV LS7 engines is a sequential multi-port injection system featuring the Super Victor manifold that comes preassembled with high-flow injectors, fuel rails and 4150-flange throttle body.
The Edelbrock Pro-Flo 4 EFI Kit #36170 for the Chevy Gen IV LS7 engine is a fully sequential multi-port injection system designed with a fuel injector strategically positioned in each runner of the intake manifold to deliver the best fuel atomization and most even distribution to each cylinder. This system features the high-performance super Victor single-plane intake manifold that comes preassembled with high-flow injectors, fuel rails and 4150-flange throttle body. All supporting sensors are included along with wire harnesses, ECU and Android-based tablet with E-Tuner Calibration app pre-installed. The Super Victor LS7 manifold is designed with a larger cross-sectional area in the plenum and larger runners for high-horsepower and/or large cubic-inch applications. The manifold is also 0.75 inch taller than the standard LS3 version to promote smoother airflow into the rectangular-port heads. This kit uses 42 Lb/Hr injectors and is rated for 675 horsepower at 58 PSI of fuel pressure. Calibration of the Pro-Flo 4 is a simple process with a Setup Wizard providing guidance through the E-Tuner's initial programming. Once provided with basic information such as type of engine, cubic inches, firing order, and cam profile, the E-Tuner then selects the most appropriate base calibration. Once the base calibration is set, the self-learning E-Tuner takes over to continually maximize the fuel map for your specific engine configuration, even compensating for changes in altitude and weather. The E-Tuner provides more advanced tuning options that allow precise control over cold starts and acceleration while retaining the simplicity that Pro-Flo systems are known for. No laptop tuning is required.
- Complete Engineered System For The Ultimate In Performance
- Self Learning EFI System
- New ECU Preloaded w/80 Dyno-Tuned Calibrations
Application Summary:
| Year |
Make/Model |
| 2009-2019 |
Cadillac CTS |
| 2007-2020 |
Cadillac Escalade |
| 2007-2020 |
Cadillac Escalade ESV |
| 2007-2013 |
Cadillac Escalade EXT |
| 2010-2020 |
Chevrolet Camaro |
| 2017-2019 |
Chevrolet Cheyenne |
| 2008-2019 |
Chevrolet Corvette |
| 2009-2020 |
Chevrolet Silverado 1500 |
| 2014-2017 |
Chevrolet SS |
| 2019-2020 |
Chevrolet Suburban |
| 2008-2009 |
Chevrolet Tahoe |
| 2018-2020 |
Chevrolet Tahoe |
| 2008-2020 |
GMC Sierra |
| 2007-2020 |
GMC Sierra 1500 |
| 2007-2020 |
GMC Yukon |
| 2015-2020 |
GMC Yukon XL |
| 2007-2014 |
GMC Yukon XL 1500 |
| 2008-2009 |
Hummer H2 |
| 2009 |
Pontiac G8 |
