One of the biggest weapons in oil-control technology is the trap-door baffle within an oil pan. Unlike static baffles, trap-door baffles open and close to allow almost unrestricted one-way fluid flow, while effectively limiting flow in the opposite direction. The baffle assemblies are arranged in a way that allows oil to move from non-pickup areas to the sump pickup area, through the use of baffle doors that have wire hinges that open approximately 1/3 of the way (so the door can close quickly without allowing too much oil to pass through).
- Wet Sump
- 16G Steel
- 7qt
- 2/6 deep front/rear
- Trap Door Baffle
- 8.5L & 8 5⁄8W
- For Dart LS Next Engines with Spacer Kit (PN: 22934): '67-92 Camaro/'68-78 Nova/'65-72 Chevelle/'53-96 Corvette/'78-88 G-Body & GM S10-S15 2WD Blazer/Truck
Additional Information:
