One of the biggest weapons in oil-control technology is the trap-door baffle within an oil pan. Unlike static baffles, trap-door baffles open and close to allow almost unrestricted one-way fluid flow, while effectively limiting flow in the opposite direction. The baffle assemblies are arranged in a way that allows oil to move from non-pickup areas to the sump pickup area, through the use of baffle doors that have wire hinges that open approximately 1/3 of the way (so the door can close quickly without allowing too much oil to pass through).
- Wet Sump
- Steel
- Trap Door Baffle
- Core Based
- 7qt
- 8.5 Deep
- For 429-460 & Tube-chassis Bracket/Super Classes: dragsters/roadsters/door slammers/etc.
- Stock pan rail bolt pattern
- Provision for Moroso Dipstick (PN: 25970/25971/25973)
