2 X 8 " / 200.3mm Slot Vented Subwoofer Microbox

DESMB8D

Diamond Audio expands on the success of its MICROBOX enclosures and is now offering 8", 10", and 12" Active Subwoofer Enclosures to its product mix. An array of Active enclosures that consist of 8”, 10”, and 12” subwoofers makes this category one of the most complete in the industry!

Features:

• 500W RMS, 1000W MAX Power Handling Subwoofer
• Single Voice Coil
• 500 Watt Class-D Amplifier
• Bass Boost: 0 /+6dB/+9dB Twin T-Filter (narrow Q)
• LPF Filter: 50-150Hz
• Phase: Variable 0 to 180 degrees
• PWM MOSFET Power Supply/Thermal Protection Circuit
• Adjustable Input Sensitivity: 0.2V -10V

Specifications:

• Subwoofer Size  8"
• Nominal Impedance (ohms)  2Ω
• RMS Power Rating  500W
• Grille  YES
• Dimension - Length x Width x Height - Inches(mm)  35” (889mm) X 6” (152.4mm) X 12” (304.8mm)
