Description

ICON Vehicle Dynamics K73003 1-3 Stage 3 Suspension System, Small Taper

K73003

2007-2016 GM 1500 1-3 inch LIFT STAGE 3 SUSPENSION SYSTEM (SMALL TAPER)

This system features upper control arms with ICON's patented Delta Joint. The Delta Joint is a heavy-duty high angle ball joint that combines the durability of a ball joint with the performance characteristics of a traditional uniball. While the industry standard uniball does a great job of allowing the control arms of a vehicle to articulate with little bind, they do have an inherent weakness that leaves more to be desired when used in a daily driven application - exposure to the elements. The Delta Joint features a zinc plated housing providing the first layer of corrosion resistance, while a tough grease seal keeps potentially harmful elements out of the inner workings of the joint. Metal on metal construction and a greaseable design increase the longevity of the Delta Joint while at the same time allowing for noise-free operation. What makes the Delta Joint unique is that it brings the best of both worlds to ICON upper control arms with features that make it more robust than a uniball, and at the same time capable of greater angularity than a typical ball joint.
  • Fits 2WD and 4WD models
  • 2.5 Aluminum Series rear shocks feature one-piece impact extruded aluminum cylinders for excellent corrosion resistance and consistent finish
  • 100% Bolt-on system - no drilling, cutting, or welding necessary for install
  • Increased wheel travel and ride quality over stock with no change in towing capacity
  • Vehicle specific tuned front and rear shocks for superior shock damping and control
  • Adjustable coilovers from 1-3 inch of lift height
  • 6061 Aircraft grade aluminum CNC machined components
  • Corrosion resistant CAD plated coilover shock bodies with 7/8 shafts
  • High strength alloy CNC machined lower bar pin
  • FK rod end bearings for extended longevity and minimal deflection

Information:

TECH NOTE: Only compatible with OE spindles. DO NOT install in combination with ANY aftermarket spindles.

Application Summary:

Year Make/Model
2007-2016 Chevrolet Silverado 1500
2007-2016 GMC Sierra 1500
Fitment
